Name: High Quality LCD Backlight Cable Continuity Tester Anti-interference Network Tools Multi Function Line Finder Digital Multimeter
Brand: Guangzhou Qingmai Electronics Co., Ltd.
Availability: InStock

Home Products Multimeter

High Quality LCD Backlight Cable Continuity Tester Anti-interference Network Tools Multi Function Line Finder Digital Multimeter

Product Details:

Contact Now

Detailed Product Description

保修期:	1年	原产地:	Guangdong, China
型号:	NF-8209	尺寸:	其他
材料:	ABS + 电气部件	Weight:	0.68KGS
工艺类型:	网络PoE检查器	放大倍率:	10倍
侵入防护:	Ipx7	使用:	FTTX FTTH FTTB
网络:	无，4g，3g	电源:	AAA电池 * 3, 电子
试验长度:	CAT5、CAT6 (STP和UTP)	跟踪类型:	CAT6 CAT5 (STP和UTP)
港口:	RJ45,POE	POE测试:	检查POE (以太网供电) Stwich标准af/at
颜色:	黑色	认证:	CE

High Quality LCD Backlight Cable Continuity Tester Anti-interference Network Tools Multi Function Line Finder Digital Multimeter

Product Overview

Feature

1. Two scan modes selectable: AC filter & Non AC filter.

2. Detect AC voltage presence (50V-1000V).

3. Test physical status for STP, UTP lan cable.

4. Measure cable length accurately , the range is 200m.

5. Hub blink for locating network port by the flashing port light on Hub / Switch. Available to 10M/100M/1000M Hub/ switch.

6. PoE testing : identify which pins are providing power and detect how much voltage, identify which the type of PSE (at/af standar).

Specification

Power	ElectronicPower supply
Power supply	AAA battery*3
Material	ABS+electric parts
Port	RJ45,POE
Test length	CAT5,CAT6 (STP & UTP)
POE test	Check the POE (power over ethernet) stwich standard af/at
Product name	Network Cable Tester
Color	Black
